Bi-conical roller cylinder blast machine

CYM Materiales GAR line continuous shot blasting machine with double-cone (diabolo) roller conveyor (RD) for high-production LPG, CNG and industrial gas cylinders. The double-cone profile rollers provide more stable cylinder advance and rotation than inclined roller models, especially in high-power blast wheel configurations and at higher production speeds. The GAR 600 RD model, equipped with 2 × 60 HP blast wheels, achieves outputs of 520 to 800 cylinders per hour on new unpainted cylinders. It is the recommended solution for large gas filling plants and LPG cylinder manufacturers requiring maximum production capacity.

• GAR 600 RD model: 2 × 60 HP blast wheels — output 520 to 800 cylinders/hour on new unpainted cylinders.
• Double-cone roller profile: greater rotational and feed stability than RI inclined rollers.
• Integrated roller double-cone conveyor — cylinder advance and rotation without additional mechanisms.
• Maximum cylinder diameter: 400 mm — suitable for LPG, CNG, O₂, acetylene and industrial gas cylinders.
• Recommended for large filling plants and high-capacity cylinder manufacturers.
