Alloy selection guide for steel casting

The alloy a part is cast in determines how it will behave in service: how long it will last, what loads it will bear and under what environmental conditions it can work. Choosing the wrong material is one of the most frequent causes of premature failure in cast parts. This guide explains the technical criteria that guide the selection of the right alloy according to the real working conditions of each part.

1. The four variables that define the choice

Before choosing a material, the part's working conditions must be characterized in four dimensions: mechanical stress (tension, compression, fatigue from cyclic loads, impact), corrosion exposure (moisture, chemical environments, salt water), service temperature (from cryogenic to continuous high temperatures) and wear (abrasion, friction, erosion). A single variable rarely dominates — most parts combine several demands, and the right alloy is the one that best balances all the conditions present.

2. Mechanical strength — carbon steel and alloy steels

When the priority is to bear loads without deforming or breaking, the reference families are carbon steel and alloy steels. Carbon steel offers high tensile strength and good machinability at competitive cost, ideal for structures and general machinery. When loads are cyclic and severe — gears, shafts, pinions — alloy steels with chromium, nickel, molybdenum and vanadium provide the fatigue resistance that carbon steel does not reach, with properties adjustable according to composition.

3. Corrosion resistance — stainless steels

When the part works in humid, chemical or outdoor environments, the chromium content of stainless steel forms the passive layer that protects it. The choice within the stainless family depends on the balance between hardness and resistance: martensitic stainless (chromium 12–18%, hardenable by heat treatment) combines high surface hardness with moderate corrosion resistance — ideal for pumps, valves and blades — while austenitic stainless prioritizes corrosion resistance and stability at high temperatures for the chemical industry, food industry and thermal components.

4. Extreme temperature — refractory steels

Parts working in furnaces, boilers, heat exchangers or engine components subjected to repeated thermal cycles require refractory steels. These alloys maintain their structural integrity and oxidation resistance at temperatures that would degrade ordinary steel, preserving dimensional stability under continuous thermal expansion and contraction.

5. Severe wear — abrasion-resistant steels

When the part is exposed to constant friction, impact and abrasion — mining, transport of abrasive materials, blast machines — abrasion-resistant steels of high carbon and alloy elements provide maximum surface hardness. This is the same family of alloys that CYM Materiales uses to cast the wear parts of its own blast machines: blades, liners and internal components of high chromium and manganese. This internal experience guarantees process mastery for parts subjected to the most demanding wear conditions.

6. Why composition control is decisive

An alloy only fulfills its function if its chemical composition is correct. A deviation in the content of chromium, carbon or alloy elements radically changes the behavior of the part in service. That is why every melt at CYM Materiales is controlled by optical emission spectrometer, guaranteeing that the specified chemical composition is met in each part. The customer receives the chemical composition, hardness and non-destructive testing report along with the finished part.
